When should I choose a planetary counter-current mixer instead of a twin shaft mixer?

Choose a vertical-shaft planetary counter-current mixer when the mix is dry, fibre-reinforced, pigmented or ultra-high performance: UHPC, GFRC, refractory castables, dry-cast paving blocks and precast elements requiring homogeneity below 5% coefficient of variation. A twin shaft mixer is the more economical choice for high-throughput ready-mix and wet concrete above 2 m³ per batch, where cycle times of 30-45 seconds matter more than micro-homogeneity.

How long does a CO-NELE mixing pan liner and blade set last?

With standard high-chrome wear parts, liners and mixing arms typically run 90,000-150,000 batches on normal concrete and 40,000-60,000 batches on abrasive mixes such as refractory castables or quartz-rich UHPC. All wear parts are bolt-on and replaceable in the field, and CO-NELE keeps interchangeable spares for every model produced since 2004.

Can CO-NELE run a trial with my own raw material before I place an order?

Yes. Our laboratory in Qingdao operates lab-scale intensive mixers and granulators from 5 to 75 litres. Send 10-20 kg of your powder or aggregate with the target particle size, moisture and capacity, and our process engineers return a test report with granule sphericity, bulk density, mixing time and the recommended production model.

What voltage, documentation and after-sales support do export buyers receive?

Machines are built to the buyer's local supply (220V/380V/415V/440V, 50 or 60 Hz), supplied with CE-compliant electrical design on request, foundation and wiring drawings, an English operation and maintenance manual, and a 12-month warranty on the drive unit. Installation guidance is delivered by video commissioning or by resident engineers; spare parts ship from stock in Qingdao.

China Cement pipe concrete mixing plant Manufacturer, Machine

1 / 1

China Cement pipe concrete mixing plant Manufacturer, Machine

Send Inquiry

Product Description

Ready mix Cement pipe concrete mixing plant price with CO-NELE planetary concrete mixer or twin shaft concrete mixer for sale

1) High intensity and efficiency, can be applied to mix four types of ingredients

2) CO-NELE planetary concrete mixer and twin shaft concrete mixer, excellent mixing performance with high efficiency and high productivity and High homogenization

3) Adopts latest controlling technology as electronic weighting system, computer controlling and digital display

4) Excellent environmental protection, dust collection system and anti-noise design

5) SIEMENS PLC, TOLEDO load cell

6) CE, ISO9001, SGS certifications

Model	HZN60	HZN90	HZN120	HZN150/180	HZN240
Capacity	60m3/h	90m3/h	120m3/h	180m3/h	240m3/h
Mixing system	Twin shaft concrete mixer/Planetary concrete mixer
Aggregate feeder	Belt conveyor/Climb the bucket conveyor
Discharging height	3800mm	3800mm	3900mm	4000mm	4000mm
After-sale service	Erection & commissioning, operator training
Warranty	12 months after erection
Concrete mixer	JS1000/CMP1000	JS1500/CMP1500	JS2000/CMP2000	JS3000/CMP3000	JS4000/CMP4000
Discharging volume	1000L	1500L	2000L	3000L	4000L
Charging volume	1500L	2250L	3000L	4500L	6000L
Mixing circle	72s
Max. mixing size	80/60mm
Aggregate batching machine	PLD1600	PLD2400	PLD3200	PLD4800	PLD4800
Storage bins quantity	2 or 3 or 4 sorts	3 or 4 sorts	3 or 4 sorts	3 or 4 sorts	3 or 4 sorts
Aggregate scale hopper	1600L	2400L	3200L	4800L	4800L
Weighing system	Water, Cement, Additive
Weighing precision	±1%
Air system	Air compressor, etc
Control system type	Computer auto-control module (PLC can be optional item)

Frequently Asked Questions (FAQ)

What types of concrete mixers are compatible with this plant?

The plant supports both CO-NELE planetary concrete mixers and twin-shaft concrete mixers, delivering excellent mixing performance and high homogenization for cement pipe production.

What capacities are available for the HZN series concrete mixing plants?

We offer multiple capacity options ranging from 60m³/h (HZN60) up to 240m³/h (HZN240) to accommodate various production scales.

How accurate is the electronic weighing system?

Equipped with SIEMENS PLC control technology and TOLEDO load cells, our weighing system achieves a high precision of ±1% for water, cement, and additives.

What international certifications do these mixing plants carry?

Our concrete mixing plants are fully certified with CE, ISO9001, and SGS standards, ensuring high quality, reliability, and safety.

What after-sales support and warranty are provided?

We offer complete erection and commissioning services along with operator training. The plant comes with a 12-month warranty starting after erection.

How does the plant address environmental protection?

The mixing plant features an advanced dust collection system and anti-noise design, meeting strict environmental protection requirements during operation.
